Web Application

Bootstrap

The most popular front-end framework for developing responsive, mobile first projects on the web.

Bootstrap web site...

DataTables

Language file e.g. DataTableDE.json

DataTables web site...

Modernizr

Modernizr adds classes to the html tag element which allow you to target specific browser functionality in your stylesheet. You don't actually need to write any Javascript to use it. Modernizr is a small and simple JavaScript library that helps you take advantage of emerging web technologies (CSS3, HTML5) while still maintaining a fine level of control over older browsers that may not yet support these new technologies.

Switchery

Switchery is a simple component that helps you turn your default HTML checkbox inputs into beautiful iOS 7 style switches in just few simple steps. You can easily customize switches, so that they match your design perfectly.

Switchery web site...

SOWI Layout

SOWI Web layout modifications

\Content\Site.css

References

SOWI Components

Reference	What does it need?
SIC
SOWIApp.Administrator
SOWIApp.Foundation
SOWIData
SOWIData.Helper
SOWIData.Management
SOWIWeb.Foundation
SOWIWeb.Helper

Routing

This example implement in Global.asax.cs puts global routing.

C#

Copy

public class MvcApplication : System.Web.HttpApplication
{
  ...

  /// <summary>
  /// SOWI Web application start event. Puts global routes.
  /// </summary>
  protected void Application_Start()
  {
      SOWIWeb.Foundation.App.RouteConfig.RegisterRoutes(RouteTable.Routes);

      ...
  }
}

Exception Handling

This example implement in Global.asax.cs so handle SOWIWeb.Foundation all exceptions

C#

Copy

public class MvcApplication : System.Web.HttpApplication
{
  ...

  /// <summary>
  /// Application Error Handling with Redirection
  /// </summary>
  /// <seealso cref="SOWIWeb.Foundation.App.ExceptionHandler.Message(System.Web.HttpApplication, string)"/>
  protected void Application_Error(object sender, EventArgs e)
  {
      SOWIWeb.Foundation.App.ExceptionHandler.Message(this);
  }
}

Definition the layout in file \Views\_ViewStart.cshtml

This example uses standard layout of FormsLayout

@{
    Layout = "~/Views/Form/Layout.cshtml";
}

Main layout with login form (without translation)

Main layout when user is logged in and without module menu (without translation)

This section contains the following subsections:

• Default parts of Layout view
• Layout options

Default parts of Layout view

Enumeration of layout parts see SOWIWeb.FoundationForms

Methods about this see FormsExtensions

Enumeration of dialogs see SOWIWeb.FoundationDialogs

Methods about this see DialogsExtensions

Layout options

Details about web conhtroller see

SOWIWeb.HelperControllerStandardDataItemClass

Default views: Index, Details, Create, Edit and Delete. This CSHTML files stored into project folder ~/Views/ and controller name.

This files has following source code for content within views built by standard Form.

@Html.Partial("~/Views/Form/Form.cshtml")

Default content: SOWI Web Helper standard web controller puts path for view content CSHTML files and SOWI Web Foundation standard has view content as CSHTML files

An example for standard content path ~/Views/Form/EditContent.cshtml

An example for customer content path ~/Views/SchachtZeichnung/EditContent.cshtml

This can be combination see example this has two columns (first column data as standard content and secound column displayed the image)

<div class="row">
    <div class="col-md-6">
        @* standard Edit Content from SOWI Web Foundation *@
        @Html.Partial("~/Views/Form/EditContent.cshtml")
    </div>
    <div class="col-md-6">
        @if (Model.Content == null)
        {
            <div class="alert alert-danger" role="alert">
                Keine Schacht Zeichnung vorhanden!
            </div>
        }
        else
        {
            var lValue = System.Convert.ToBase64String(Model.Content, 0, Model.Content.Length);
            string lName = "Content";
            <img src="@lImage" alt="Schacht Zeichnung" />
            <input type="hidden" name="@lName" id="@lName.GetMVCFieldIdentification()" value="@lValue" />
        }
    </div>
</div>

Structure see parts of layout

For view form contents enumeration see SOWIWeb.HelperContents

An example does define the custom content path see ContentsExtensionsOnContentsToPath

For view form enumeration see SOWIWeb.FoundationForms

An example does define the custom view path see FormsExtensionsOnFormsToPath

Can script files declaration in view file type cshtml

Note: only first file view call from web controller
not in partial cshtml files
store App java script files in folder /Scripts/App/

An example in partial cshtml file

@section scripts
{
    <script src="~/Scripts/App/QualiTemplate.js" type="text/javascript"></script>
}

Can styles and style files declaration in view file type cshtml

Note: only first file view call from web controller
not in partial cshtml file
store App style files in folder /Content/App/

@section styles
{
    <style>
        input, select, textarea {
            max-width: 50px;
        }
    </style>
}

Or

Can styles direct write in cshtml

<style>
    input, select, textarea {
        max-width: 50px;
    }
</style>

Automatic login (only for Debug mode) into file Global.asax.cs

This example has project Settings: AutoLogin, UserName and UserPassword

public class MvcApplication : System.Web.HttpApplication
{
    ...

    protected void Application_Start()
    {
        ...

        #if DEBUG
        //* puts auto login data for debug start *
        SOWIWeb.Foundation.Properties.Settings.SetLoginData(Properties.Settings.Default.AutoLogin,
                                                            Properties.Settings.Default.UserName,
                                                            Properties.Settings.Default.UserPassword);
        #endif
    }
}

More options see also

• SOWIData.Management.InterfaceIAppOption

• Layout options

See

• Web Controller

Reference
